| Working Medium: | AIR | Medium Temperature: | -10 ～ 120℃ |
|---|---|---|---|
| Working Pressure: | 0-8bar | Valvebody Material: | Brass |
| Sealing Material: | Viton | Interface: | G Thread |
| Working Voltage: | 220V | ||
| High Light: | 3 way solenoid valve,fluid solenoid valve |
||
YSF026 brass 2-way electric iron coffee maker solenoid valve direct acting G1 / 8 " DN2 MM 220V 230V 240V
Voltage:
DC - 12V,24V AC - 24V,AC 120V, 240V@60HZ 110V, 220V@50HZ Tolerance: +/- 10%
Material:
Body - Brass or Stainless steel
Seal -NBR, EPDM, PTFE or VITON
Armature Tube - Stainless Steel 304
Plunger - Stainless Steel 430F
Stop -SS430F
Springs - SS 304
Shading Rings - Stainless Steel 304
Characteristic:
1. Direct lifting diaphragm construction;
2. Open from zero bar for low pressure system use;
3. High frequency of DIN plug coil
4. Medium:Air, City Gas, Water, Oil, Petroleum, steam,etc.
5. Pressure: 0.00MPa ~ 1.0MPa.
6. Port Thread:BSPP ,BSPT ,NPT ,Flange, UNF, M8X1
Temperature:
NBR Seal: 14F to 176F , -10 to 80
EPDM Seal: 14F to 250F , -10 to 120
VITON Seal : 14F to 300F, -10 to 150.
Port Size:3/8,1/2,3/4,1,1 1/4,1 1/2,2
Orifice (mm): 12,15,20,25,32,40,50
YSF-series solenoid valve specification table
| Model | Interface size |
Orifice size (mm) |
Cv
|
working pressure(bar) | valvebody material | note |
weight (Kg) |
|||
| steam | liquid,air,water | |||||||||
| C220V | DC24V | C220V | DC24V | |||||||
| YSF-022 | ZG 1/8＂ | 2 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | brass | Cannula φ6mm | 0.1 |
| YSF-023 | 2 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | ||||
| YSF-024 | G1/8＂ | 1.5 | 0.09 | 0～6 | 0～6 | 0～10 | 0～10 |
brass
|
0.13 | |
| 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | |||||
| 2.5 | 0.25 | 0～3 | 0～3 | 0～5 | 0～5 | |||||
| YSF-024J | G1/8＂ | 1.5 | 0.09 | 0～6 | 0～6 | 0～10 | 0～10 | SS316 | 0.13 | |
| 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | |||||
| 2.5 | 0.25 | 0～3 | 0～3 | 0～5 | 0～5 | |||||
| YSF-025 | G1/8＂ | 1.5 | 0.09 | 0～6 | 0～6 | 0～10 | 0～10 |
brass
|
3-way NO: “1”: inlet NO:cannula φ6 |
0.13 |
| 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | |||||
| 2.5 | 0.25 | 0～3 | 0～3 | 0～5 | 0～5 | |||||
| YSF-025J | G1/8＂ | 1.5 | 0.09 | 0～6 | 0～6 | 0～10 | 0～10 | SS316 |
3-way NO: “1”inlet NO:cannula φ6 |
0.13 |
| 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | |||||
| 2.5 | 0.25 | 0～3 | 0～3 | 0～5 | 0～5 | |||||
| YSF-026 | G1/8＂ | 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | brass | 0.13 | |
| YSF-027 | 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | 0.12 | |||
| YSF-028 | ZG 1/8＂ | 2.0 | 0.20 | 0～6 | 0～6 | 0～8 | 0～8 | Cannula φ6mm | 0.1 | |
