|Working Medium:||Water、liquid、air、light Oil（viscosity≤20cst）||Medium Temperature:||-5 ～ 80℃. 0-180℃|
|Working Pressure:||0 ～ 16 Bar||Environmental Temperature:||-10-50 ℃ Relative Humidity ≤85%|
|Valve Body Material:||Brass, Stainless Steel. SS 304, Cast Iron||Explosion Proof Structure:||Flameproof Exd II BT4, Encapsulation Type Exm BI/IIBT 4|
|Coil Parameters:||AC 110V AC 220V AC 240V DC 12V DC 24V Flameproof IP 54 Encapsulation Type IP 65 I Meter-long Cable Wire|
explosion proof valve,
intrinsically safe solenoid valve
1, explosion-proof solenoid valve operation and long life.
2, explosion-proof solenoid valve operating system: sub-long work, repeated short-time working and short-time work three. Explosion-proof solenoid valves are long-term work system, which allows the coil is energized to work long-term. For a long time the valve opening of the case is only a short time off, are advised to use a normally open solenoid valve. In the short-time working with large quantities when, you can make a special order to reduce power consumption.
3, explosion-proof solenoid valves operating frequency: frequency of demanding action, the structure should be optimized direct acting solenoid valve, the power to listen preferred exchange.
