| Working Medium: | Gas、air、water | Medium Temperature: | -5 ～ 80℃ |
|---|---|---|---|
| Working Pressure: | 0.3～7bar | Valvebody Material: | Brass |
| Sealing Material: | EPDM | Interface: | NPT Thread |
| Working Voltage: | DC12V 24V 220V 230V 240V | ||
| High Light: | latching solenoid valve water,latch solenoid valve |
||
asco bistable latching solenoid valve one inch brass material 12V 24V 220V 230V 240V
The valve actuator is industrial process automation control system used. It can automatically turn on or off after receiving the electric signal, the pipeline fluid medium is carried off two automatic control and remote control. This series solenoid valve can be widely used in textile, printing, chemicals, plastics, rubber, pharmaceutical, food, building materials, machinery, electronics, surface treatment and research departments as well as bathrooms, cafeteria, air conditioning, automatic control system
working medium:liquid,water,air,light oil(viscosity≤20cst)
medium temperature:-5 ～ 80℃
working pressure:0.3～16bar (details see specification table)
working type:DN1.5～4 direct acting DN15～50 pilot operated
valvebody material: brass SS316 PA66
sealing material:NBR(-5～80℃)
interface:G thread NPT thread
working voltage:DC6V DC9V DC12V DC24V
4W 6W 12W IP65 H degree
Options:
sealing material:EPDM(-10～130℃) VITON(-10～120℃)
YSZ-series pilot operated solenoid valve specification table
| model |
orifice size ( mm ) |
Interface size | Cv | working pressure(bar) |
length×width×height ( mm ) |
weight(Kg) | |||
| air | Water liquid | brass | SS | PA66 | |||||
| YSZ - 15 | 14 | 1/2＂ | 3.5 | 0.3～16 | 0.3～12 | 66×48×112 | 0.7 | 0.6 | |
| YSZ - 20 | 20 | 3/4＂ | 7.6 | 0.3～16 | 0.3～12 | 75×58×118 | 0.8 | 0.7 | |
| YSZ - 25 | 25 | 1＂ | 12 | 0.3～16 | 0.3～12 | 96×69×125 | 1.3 | 1.2 | |
| YSZ - 32 | 32 | 11/4＂ | 22 | 0.3～16 | 0.3～10 | 131×96×125 | 2.8 | 2.8 | |
| YSZ - 40 | 40 | 11/2＂ | 30 | 0.3～16 | 0.3～10 | 131×96×150 | 2.6 | 2.6 | |
| YSZ - 50 | 50 | 2＂ | 48 | 0.3～16 | 0.3～10 | 168×128×165 | 3.9 | 3.6 | |
| YSZ–15SL | 15 | 1/2＂ | 3.5 | 0.3～7 | 0.3～7 | 85×73×126 | 0.6 | ||
| YSZ–20SL | 20 | 3/4＂ | 7.6 | 0.3～7 | 0.3～7 | 90×73×128 | 0.6 | ||
| YSZ–25SL | 25 | 1＂ | 12 | 0.3～7 | 0.3～7 | 125×90×148 | 0.6 | ||
| YSZ–32SL | 32 | 11/4＂ | 22 | 0.3～7 | 0.3～7 | 150×128×173 | 0.8 | ||
| YSZ–40SL | 40 | 11/2＂ | 30 | 0.3～7 | 0.3～7 | 152×128×176 | 0.9 | ||
| YSZ–50SL | 50 | 2＂ | 48 | 0.3～7 | 0.3～7 | 170×140×190 | 1.1 | ||
