24VDC 1 / 8 " Miniature Solenoid Valve Normally Closed NC Low Pressure

24VDC 1 / 8 " Miniature Solenoid Valve Normally Closed NC Low Pressure
24VDC 1 / 8 " Miniature Solenoid Valve Normally Closed NC Low Pressure

Large Image :  24VDC 1 / 8 " Miniature Solenoid Valve Normally Closed NC Low Pressure

Product Details:
Place of Origin: China
Brand Name: Round Star
Certification: CE/ROHS/TUV/FDA
Model Number: RST
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiation
Packaging Details: exporting condition
Delivery Time: 3 working days after received your payment
Payment Terms: Western Union, MoneyGram, T/T
Supply Ability: 5,000pcs per month
Detailed Product Description
Working Medium: Liquid Medium Temperature: -5 ~ 80℃
Working Pressure: 0-2bar Valvebody Material: Brass
Sealing Material: NBR Interface: NPT Thread
Working Voltage: 24V
High Light:

micro solenoid valve

,

small solenoid valve

RST brass miniature solenoid valve direct acting normally closed NC 1 / 8 " - 1 / 4 " DC24V 12V



Features



1. Direct acting miniature consruction at low power consumption



2. Compact design to save the space



3. Applied to low pressure system , open from 0 bar



24VDC 1 / 8 " Miniature Solenoid Valve Normally Closed NC Low Pressure 0

RSSM RSW RST-series 2-way direct acting solenoid valve specification table

model interface size

orifice size

(mm)

Cv



working pressure(bar) power valvebody material

weight

(Kg)

AC220 DC24V AC220V DC24V
RSSM-2 1/8" 2 0.12 0~10 0~8 10VA 8W

brass



SS316

0.3
RSSM-3 1/4" 3 0.20 0~8 0~7
RSSM-4 1/4" 4 0.3 0~6 0~5
RSW-015 1/8" 1.5 0.06 0~15 0~12 13VA 10W brass 0.26
RSW-020 2.0 0.12 0~10 0~8
RSW-025 2.5 0.20 0~8 0~6
RSW-030 3.0 0.25 0~6 0~5
RST-015

1/8"

OR

1/4"

1.5 0.06 0~20 0~15 15VA 12W brass 0.23
RST-020 2.0 0.12 0~12 0~10
RST-025 2.5 0.20 0~10 0~6
RST-030 3.0 0.25 0~8 0~3
RST-040 4.0 0.3 0~6 0~2



24VDC 1 / 8 " Miniature Solenoid Valve Normally Closed NC Low Pressure 1
